The IE5+ synchronous motors within the 112 body dimension from NORD. | Supply: NORD DRIVESYSTEMS
NORD DRIVESYSTEMS expanded its IE5+ synchronous motor line with the brand new 112 body dimension. The brand new SK 112 motor dimension extends the facility of compact IE5+ everlasting magnet synchronous motors to fifteen.0 hp.
IE5+ everlasting magnet synchronous motors (PMSM) from NORD DRIVESYSTEMS ship excessive power effectivity. Everlasting magnet expertise makes use of high-strength everlasting magnets to create a relentless magnetic subject, eliminating the necessity for exterior excitation and leading to extraordinarily excessive effectivity of as much as 95%, excessive energy density, and important power financial savings.
NORD provides IE5+ motors in sizes 71, 90, and newly launched, dimension 112, extending the facility vary from 0.5 to fifteen.0 hp and torque as much as 387 lb-in.
Contained in the IE5+ motor vary
IE5+ synchronous motors ship fixed torque and effectivity over a large velocity vary, even at partial load and low speeds. This permits lowered system variants, minimized administrative bills, and leaner manufacturing, logistics, storage, and repair processes.
Ventilated variations (TEFC) can be found in all 3 body sizes and have a finned housing that gives superior warmth dissipation, splendid for steady responsibility intralogistics purposes. Easy physique, non-ventilated variations (TENV) can be found in motor sizes 71 and 90 and supply a corrosion-resistant choice in hygienic environments resembling meals and beverage purposes. IP69K Safety Class is moreover out there with TENV variations for an easy-to-clean floor that may face up to harsh environments.
IE5+ motors considerably exceed the very best outlined power effectivity class, significantly lowering their power consumption and CO2 emissions.
Along with contemplating power effectivity, the motors additionally contemplate materials effectivity. They characteristic an modern 8-pole Inside Everlasting Magnet (IPM) design that reduces the variety of lively motor elements, leading to materials financial savings relating to the sheet steel and magnets. The stator can be manufactured with single-tooth winding, lowering the usage of copper within the winding head.
Drive options from NORD are all the time configured to particular person utility necessities, creating the perfect system for every venture. IE5+ synchronous motors additional increase their system capabilities with compatibility throughout their product vary of drugs items and digital management initiatives.
The motors are geared up with a typical incremental encoder and have further choices together with an built-in mechanical brake, motor connectors, absolute or magnetic encoders, and numerous flange mountings for gear unit attachment in addition to direct mounting. Regardless of the appliance, IE5+ PMS motors assist customers obtain elevated operational effectivity, lowered whole price of possession, and a quick return on funding.
NORD additionally develops and produces a variety of drives for greater than 100 industries and equipment items for torques from 10 Nm as much as over 282 kNm. It additionally provides electrical motors within the energy vary of 0.12 kW to 1,000 kW, in addition to the required energy electronics with frequency inverters of as much as 160 kW.
In February, NORD additionally introduced that it now provides digital twins for system improvement. Based mostly on a myNORD configuration, customers can request individually created drive methods as simulation fashions.
