Keysight’s NA5305A and NA5307A mmWave modules prolong PNA and PNA-X vector community analyzers (VNAs) to 170 GHz and 250 GHz, respectively. Paired with the 85065A 0.5-mm coaxial calibration equipment and N5292A take a look at set controller, the frequency extenders allow totally calibrated single-sweep broadband S-parameter measurements from 100 kHz (or 10 MHz) as much as 250 GHz.
The broadband VNA equipment simplify take a look at setups and allow engineers to characterize on-wafer or packaged elements at sub-THz frequencies. In addition they assist speed up the design and validation of 1.6‑Tb/s and three.2‑Tb/s elements and next-generation semiconductors.
Check configurations present a dynamic vary of 105 dB at 170 GHz for passive elements, high-rejection filters, and energetic gadgets. Differential measurements assist validate energetic gadgets and high-speed interconnects, with most output energy of 0 dBm at 170 GHz and –5 dBm at 220 GHz.
Present 110‑GHz and 120‑GHz VNA customers can simply improve their configuration to protect their unique funding.
