Engineered for 5G, automotive, and telecom purposes, new 3dB 90° hybrid couplers ship high-frequency efficiency in a miniature footprint—enabling smarter, smaller, and extra environment friendly RF designs.
KYOCERA AVX has launched a brand new line of built-in skinny movie (ITF) hybrid couplers, engineered to fulfill the demanding efficiency and dimension necessities of rising high-frequency wi-fi methods. The brand new DB0402 3dB, 90° hybrid couplers leverage superior multilayer thin-film know-how to ship best-in-class efficiency within the 3,000–4,100MHz frequency vary. These four-port directional couplers cut up alerts into two equal-amplitude outputs, phase-shifted by 90°, with minimal insertion loss and superior amplitude and part steadiness.
The important thing options are:
- Extremely-miniature dimension: simply 0.040” x 0.023” x 0.014”
- Excessive energy dealing with: as much as 1W steady
- Low insertion loss: as little as -0.5dB
- Excessive sign isolation for clear efficiency
- Vast working temperature vary: -40°C to +85°C
The strong design ensures dependable efficiency even in harsh environments, whereas the ultra-miniature dimension helps save useful board house, making it a super selection for compact RF layouts. The design additionally ensures low parasitics, and glorious repeatability throughout manufacturing batches. Additionally they help a number of soldering strategies and are packaged on tape and reel for simple integration into automated meeting strains. Full RoHS and IATF compliance additional improve their suitability for high-reliability environments.
Designed to speed up the efficiency of high-frequency wi-fi applied sciences, these hybrid couplers are optimized for a wide selection of RF purposes, together with 4G/5G/6G LTE infrastructure, MIMO antenna methods, GPS, satellite tv for pc TV, RF balanced amplifiers, sign distribution, wi-fi LANs, automobile monitoring, and heavy-duty radios. Their excessive linearity and efficient warmth dissipation make them excellent for mission-critical industrial, automotive, telecom, and telemetry options the place sign integrity and house effectivity are paramount.
“Hybrid couplers like these are essential enablers of contemporary wi-fi networks,” stated Mohammed Abu-Naim, RF Product Supervisor, KYOCERA AVX – North America. “As 5G and SATCOM applied sciences evolve, so should the elements behind them. Our new couplers provide RF engineers the reliability, efficiency, and compactness wanted for the following era of wi-fi innovation.”
For extra info, click on right here.
