Designed for superior analysis in high-speed electronics, semiconductors, and physics, the oscilloscopes ship ultra-fast sign seize with beneath 12 ps rise instances and
Pico Expertise has introduced the enlargement of its PicoScope 9400A Sequence, including three new fashions to its line of high-bandwidth sampling oscilloscopes. These devices are tailor-made to the evolving calls for of high-speed electronics, communications, semiconductor analysis, and high-energy physics.
Constructed on the corporate’s superior Sampler eXtended Actual-Time Oscilloscope (SXRTO) know-how, the prolonged 9400A Sequence now provides bandwidth choices of 6 GHz, 16 GHz, 25 GHz, and a brand new flagship 33 GHz mannequin. The 33 GHz oscilloscope achieves distinctive sign constancy with rise and fall instances beneath 12 picoseconds—essential for correct evaluation of ultra-fast digital alerts. All fashions embody 4 enter channels, 12-bit vertical decision, and an industry-leading jitter efficiency of lower than 1.5 picoseconds RMS, making certain high-precision time-domain measurements.
A key function accessible throughout the vary is non-compulsory clock restoration, enabling the devices to generate triggers from acquired information alerts—supreme when separate set off traces are unavailable. This flexibility is particularly helpful for analyzing advanced, high-speed information streams.The important thing specs embody:
- Variety of Enter Channels: 4 (similar, concurrently digitized)
- Place Vary: ±4 divisions from heart display
- Working Enter Voltage: ±1 V and ±800 mV
- ADC Decision: 12 bits
- Enter Impedance:50 ± 1.5 Ω and 50 ± 1 Ω (typical)
These compact, PC-based devices are perfect for integration into automated take a look at setups or shared laboratory benches. Designed with usability and efficiency in thoughts, the brand new PicoScope 9400A fashions are notably fitted to purposes in semiconductor characterization, superior supplies analysis, and high-frequency communications.
Every oscilloscope within the sequence is powered by PicoSample 4 software program for Home windows, providing deep visualization and a complete suite of measurement and evaluation instruments. Customers can carry out pulse and eye diagram measurements on RZ, NRZ, and PAM4 encoded alerts—important for evaluating sign integrity in as we speak’s high-speed methods.
Trevor Smith, Product Supervisor at Pico Expertise, commented, “This prolonged sequence delivers world-class efficiency in a compact, cost-effective kind issue. It meets the wants of engineers and researchers engaged on cutting-edge applied sciences whereas becoming seamlessly into space-constrained and budget-conscious lab environments.”
