Stronger grip, longer life, and constructed for harsh situations. These connectors might change how industrial techniques work. See what makes them totally different.
Harwin has expanded its Kontrol connector vary with by way of gap retention, boosting mechanical power and PCB reliability in demanding environments. The replace provides 72 new merchandise, rising the vary by 48%, and is now obtainable in tape-and-reel packaging for automated meeting. All fashions are lead-free, free from restricted substances, absolutely RoHS compliant, and include no REACH SVHCs.
Checks present the by way of gap retention function delivers as much as twice the PCB holding pressure of surface-mount variations. The connectors are rated for 500 mating cycles and might face up to vibration ranges of 20 G for as much as 12 hours.
Every connector has a 1.27 mm (0.05 inch) pitch, affords 9 pin-count choices from 6+6 to 40+40, and is available in vertical and horizontal codecs for compact layouts. They’re absolutely shrouded with recessed contacts for defense, polarized for one-way meeting, and outfitted with location pegs for correct soldering. The design additionally permits for top misalignment tolerance, with linear offsets of two° to 4° ± 1° relying on kind.
HaThe firm has developed the growth to fulfill rising industrial calls for for vibration resistance, greater knowledge throughput, and area effectivity by incorporating options from its high-reliability ranges into the Kontrol collection.
A few of the key options of the connector vary embrace:
- Sturdy maintain on PCB (2× greater than surface-mount).
- Handles 20 G vibration for 12 hours.
- Works for 500 join/disconnect cycles.
- 1.27 mm pitch, 6+6 to 40+40 pins.
- Vertical or horizontal choices.
- Protected, one-way match with location pegs.
- RoHS compliant, no restricted substances.
“Industrial and embedded functions usually endure tight value constraints, however are actually going through exceptionally harsh environments,” mentioned John Feaster, Product Supervisor BBi Connectors at Harwin. “Harwin and its HRi ranges are an trade chief for resilience and sturdiness, and we’re delighted to deliver these options to industrial environments.”
